UHMWPE Fabric
  2021/09/28| View:21

Description:

UHMWPE Fabric is a new generation of high performance fiber after the carbon fiber and aramid fiber. UHMWPE fiber has the best mechanical property of all the fibers. UHMWPE has super high strength, high modulus, light proportion, low rupture and elongation rate, ultraviolet radiation resistance, chemical corrosion resistance, wear resistance, cut resistance, UV stability and other features.

We have 3 styles of UHMWPE Fabric: JL130-2, JL130-2, JL160-3.


Specification List:

Style

Specification    ( Length * width)

Areal Density

Ballistic Performance

Application Criterions

JL130-2

1.2*105±5m

130±5g/m2

4.42Kg/m2

NIJIIIA 9mm

34layers

NIJ0101.04

5.46Kg/m2
NIJIIIA.44

42layers

NIJ0101.06

JL160-2

1.2*105±5m

160±5g/m2

4.23Kg/m2
NIJIIIA 9mm

26layers

NIJ0101.04

5.03Kg/m2
NIJIIIA.44

31layers

NIJ0101.06

JL160-3

1.2*105±5m

160±8g/m2

3.63Kg/m2
NIJIIIA9mm

22layers

NIJ0101.04

4.35Kg/m2
NIJIIIA.44

27layers

NIJ0101.06


Applications:

1. Bulletproof Uniforms

2. Composite with Ceramic Plate for Bulletproof

3. Cut Resistant Gloves, Uniforms, Sleeves
