Fiberglass products and resin For FRP tank
一)Fiberglass Products:
1) Inner lining layer:
FRP horizontal storage tank : 45g/m2 polyester tissue+E-glass chopped strand mat 300g/m2,450g/m2 or 30g/m2 fiberglass tissue+E-glass chopped strand mat 300g/m2,450g/m2
FRP vertical storage tank :45g/m2 polyester tissue+E-glass stitch bonded mat 300g/m2,450g/m2 or 30g/m2 fiberglass tissue+E-glass stitch bonded mat 300g/m2,450g/m2
2) enhancement layer : normally E-glass direct roving 2400tex,4800tex,sometimes use 1200tex
3) end capped : hand lay-up , E-glass woven roving 600g/m2+E-glass chopped strand mat 300g/m2,450g/m2
4) flange : hand lay-up , E-glass chopped strand mat 300g/m2,450g/m2
5) the connection between tank body and end capped : internal,external,E-glass chopped strand mat 300g/m2,450g/m2
二)Resin
1) inner lining layer : according to the type of solution in tank and the solution working temperature,you can choose suitable Vinylester resin or Unsaturated Polyester resin.
2) enhancement layer : normal Unsaturated Polyester winding resin
3) External protective layer: normal Unsaturated Polyester winding resin+UV additive
Changzhou Utek Composite Co.,Ltd.can provide these fiberglass products and resin,if you need,pls don’t hesitate to contact us.
